| Series |
HFU Series |
HFS Series |
PDF |
| Model No. |
HFU-2020 |
HFU-1020 |
HFU-2315AN |
HFS-2020 |
HFS-1020 |
| MWCO or Pore Size |
150,000 Da |
0.02 micrometer |
Toray-brochure
HFU-2315AN Spec Sheet |
Membrane Surface Area
[Outer Surface] |
72 m²
(775 ft²) |
29 m²
(312 ft²) |
60 m²
(-) |
72 m²
(775 ft²) |
29 m²
(312 ft²) |
| Design Flux(m²/hour) |
8.0 - 2.6 |
3.2 - 1.1 |
10.0 - 11.2 |
11.0 - 2.4 |
4.3 - 1.6 |
| Dimension |
Diameter |
216 ㎜
(8.50 inches) |
216 ㎜
(8.50 inches) |
178 ㎜
|
216 ㎜
(8.50 inches) |
216 ㎜
(8.50 inches) |
| Length |
2,160 mm
(7.087 ft.) |
1,120 mm
(3.675 ft.) |
2,332 mm
|
2,160 mm
(7.087 ft.) |
1,120 mm
(3.675 ft.) |
| Weight |
Full of water |
110 kg |
60 kg |
60 kg |
110 kg |
60 kg |
| After draining |
67 kg |
40 kg |
35 kg |
67 kg |
40 kg |
| Material |
Membrane |
PVDF (Polyvinylidene Fluoride) |
| Casing |
Polyvinylidene |
| Potting |
Epoxy Resin |
| Max. Inlet Pressure |
300 kpa (44 psi) |
| Operating Temperature Range |
0 - 40 degree C |
| pH Range |
1 - 10 at Filtration, 0 - 12 at Chemical Cleaning |
